Home » Products » Servo Tensioners » DS-TT Series Pulse Servo Tensioner

DS-TT Series Pulse Servo Tensioner

DS-TT Series Pulse Servo Tensioner
DS-TT Series Pulse Servo Tensioner
Send Inquiry
Product Code : 13
Brand Name : TROPHY
Product Description

The  DS-TT pulse  servo  tensioner  features  a  sensitive  and  quick  response  feedback  control  system,  providing  or  high  speed  quality  winding. Its Pulse  motor and  control  system  are  packed  within  a  body  casing  made  by  molded  ABS  plastic.  Its  design  is  solid,  compact  and lightweight.  It  operates  with  DC  24V  and  comes  with  two  stage tension settings and wire breakage detection. The series offers the following wire speed versions :7m/sec and 12m/sec.


We are regarded as the noteworthy names engaged in offering of an extensive gamut of DS-TT Series Pulse Servo Tensioner. Its pulse motor and control system are packed within a body made by molded ABS plastic. Our given servo tensioner operates with DC 24V and comes with wire breakage detection. In tune with different requirements of our clients, we provide DS-TT Series Pulse Servo Tensioner in various models and other related specifications. Application specific design, rust resistance and smooth finish are qualities of offered product.


Advantages :

  • Light weight and compact design
  • Precise, stable and consistent tension control fat quality Winding
  • Adjustment knob positioned at the front. easy adjustment
  • Built-in wile breakage detection
  • Reliable and require low maintenance


Technical Specifications of DS-TT-A07 Series

Model

Tension range (grams)

Max wire travel speed

Power source

Current consumption

Applicable wire size (mm)

DS-TT-A07-45S200

1.0g-200g

7m/s

DC24V

1.2A

0.01-0.18

DS-TT-A07-45S300

6.0g-300g

7m/s

DC24V

1.2A

0.02-0.20

DS-TT-A07-45S600

40g-600g

7m/s

DC24V

2.0A

0.05-0.35



Technical Specifications of DS-TT-A12 Series

Model

Tension range (grams)

Max wire travel speed

Power source

Current consumption

Applicable wire size (mm)

DS-TT-A12-45S200

1.0g-200g

12 m/s

DC24V

2.5A

0.01-0.18

DS-TT-A12-45S300

6.0g-300g

12m/s

DC24V

2.5A

0.02-0.20

DS-TT-A12-45S400

40g-400g

12 m/s

DC24V

2.5A

0.05-0.25

Specifications are subject to change without notice.

  • Dimensions : 214mm*169mm*84mm
  • Weight : 1 Kg
