Single Spindle Coil Winding Machine

Single Spindle Coil Winding Machine

Product Details:

  • Product Type Coil Winding Machine
  • General Use For Winding Coil
  • Power Source Electric
  • Voltage 220-240 Volt (v)
  • Color Black
  • Supply Ability : 2000 Unit Per Month
X

Price And Quantity

  • 1 Unit
  • INR/Unit

Product Specifications

  • Coil Winding Machine
  • Black
  • For Winding Coil
  • 220-240 Volt (v)
  • Electric

Trade Information

  • 2000 Unit Per Month
  • 3-4 Week
  • All India

Product Description

This machine can be adjustable to suit different winding requirement by just changing suitable Tensioner, wire guides, and winding mandrels.

This machine based on Micro controller to control the programmed parameters, it has Four line LCD module, described keyboard for enter of numeric values and parameters, it has a 100 program memory coupled with set of programmable parameters and reset auto/manual, soft starting time and soft stopping turns to achieve complex wingdings like,

  • Conical Winding
  • Sectional Winding
  • Different pitch Winding
  • Layer Winding

Our machine are available with different models as follows,

  • Single Spindle - Side loading / Front loading
  • Dual Spindle - Side loading / Front loading
  • Four Spindle - Side loading / Front Loading
  • Semi Thick wire Machine Single Spindle - Side loading
  • Thick wire Machine Single Spindle - Side Loading

These machine usages are too simple to understand the winding parameters and working of the machine


Technical Specifications

Winding Turns

0.1 to 99999.9 Turns

Winding Width

0.1 to 135.0 mm

Winding Pitch

0.02 mm to 9.999 mm

Winding Swing Diameter

110 mm (max)

Winding Speed

200 to 9000 RPM

Spindle Motor

180W, 180VDC, 1A, 4000RPM

Stepper Motor

Hybrid Stepper Motor 1.8, 1A

Brake

Electro Magnetic Disc Brake

Power Supply

220/240V AC, 50Hz, 0.2KVA

Processor

Micro Controller

Memory Type

Eeproms, 100 programs

Display

4 Line 20 character LCD Modules

Key Board

Normal Keyboard
