Hi-speed Closed Loop Servo Tensioner Icf Series

Get a Price/Quote

Product Details:

Product Type Servo Tensioner
General Use Industrial
Material ABS
Type Wire Winding Machine
Power Source Electric
Winding Speed 15 Meter/second (m/s)
Drive Type Electric
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Hi-speed Closed Loop Servo Tensioner Icf Series Price And Quantity

Minimum Order Quantity 1 Piece

Hi-speed Closed Loop Servo Tensioner Icf Series Product Specifications

Winding Speed 15 Meter/second (m/s)
Type Wire Winding Machine
Drive Type Electric
Power Source Electric
Product Type Servo Tensioner
Color Blue
General Use Industrial
Voltage 24-48 Volt (v)
Material ABS
Feature Low Energy Consumption

Hi-speed Closed Loop Servo Tensioner Icf Series Trade Information

Supply Ability 1 Piece Per Day
Delivery Time 2-3 Days

Product Description

Servo Tensioner ICF series

HI-SPEED CLOSED LOOP SERVO TENSIONER ICF SERIES

1.digital stabilization system;2.support support Controller Area Network;3.Closed-loop constant tension control4.Real-time tension measurement and display

This series of tensioners adopts DC brushless servo motor and high-precision tension control technology, which has the characteristics of high control precision and wide control range. , which can meet the needs of ultra-high-speed and high-precision winding, and can effectively improve winding efficiency and coil quality.

The tensioner is connected with data communication box through CAN bus, and realizes networking. data communication box supports

Advantages :

Please choose the tension rod and spring suitable for the tension value to use;
Do not touch the transmission and rotating parts and block the tension rod when using the tensioner;
Do not let the tensioner drop or be damaged by strong impact;
Adjust the tension value according to the need, and select the appropriate model specification.

REQUIERMENTS :

Power Supply : DC 24V /48V

BASIC SPECIFICATIONS OF ICF SERIES

Model No.	Tension Range (G)	Max Wire Travel Speed(M/S)	Power Supply	Rated Current (A)	Suitable Wire Size (Mm)
ICF 400	2-400	15	DC24V	3.5	0.02-0.25
ICF800	30-800	15	DC48V	5.5	0.06-0.40
ICF1500	80-1500	15	DC48V	7.5	0.10-0.50
ICF2000	80-2000	15	DC48V	7.5	0.10-0.65
