DSX-HCF Series Hi Speed Closed Loop Servo Tensioner With LCD Display

DSX-HCF Series Hi Speed Closed Loop Servo Tensioner With LCD Display
DSX-HCF Series Hi Speed Closed Loop Servo Tensioner With LCD Display
Send Inquiry
Product Code : 05
Brand Name : TROPHY
Product Description

Being the leading company, we are affianced in providing a wide gamut of DSX-HCF Series Hi Speed Closed Loop Servo Tensioner that is known for its high efficiency and excellent quality. The given servo tensioner features a large screen HD LCD panel for multiple data settings and display. Clear multiple data display, real-time communication and tension range preset function are qualities of offered loop servo tensioner. This DSX-HCF Series Hi Speed Closed Loop Servo Tensioner can be purchased from us at reasonable rates within the promised time period.


More Details

The  DSX - HCF series  features  high  speed  closed  loop  servo  Tensioners  with  a  maximum wire - feeding speed  of  15  meters per second.

Its high speed/high torque DC servo motor and built - in Adaptive Speed Control software provides fast response to rapid changes in coil winding speed and a wider Tension range for Hi-speed precision winding.It features a large screen HD LCD panel for multiple data settings and display.

Standard configurations for this series includes a built-in tension measurement system, two-stage tensions setting and wire breakage detection.

The series operates with  DC24V .


Advantages

  • Precise, stable and consistent tension for hi -speed precision winding

  • Two stage tension setting

  • Clear Multiple data display: real time tension, real time wire speed and real time wire length

  • Tension Range preset function (upper and lower tension limit) with alarm output

  • Real time communication with host computer, collect and record winding data (tension diagram, wire length, wire travel speed etc.,)


Technical Specifications

Model

Tension Range (grams)

Max Wire Travel speed

Current Consumption

Applicable wire size (mm)

Dimensions(mm)

Weight (Kg)

15m/s

2.5A

0.01-0.25

330x210x80

2.0

Specifications are subject to change without notice.


Requirements :

  • Power supply : DC 24V

  • Compressed air. 5kg/cm2
