Servo Tensioner - DS-CF Series
Product Details:
- Product Type Servo Tensioner
- General Use Industrial
- Material ABS
- Type Wire Winding Machine
- Power Source Electric
- Drive Type Electric
- Feature Low Energy Consumption
- Click to View more
X
Servo Tensioner - DS-CF Series Price And Quantity
- 1 Piece
Servo Tensioner - DS-CF Series Product Specifications
- Low Energy Consumption
- Blue
- Electric
- ABS
- Industrial
- Servo Tensioner
- Wire Winding Machine
- Electric
Servo Tensioner - DS-CF Series Trade Information
- 1 Piece Per Day
- 2-3 Days
Product Description
HI-SPEED CLOSED LOOP SERVO TENSIONER DS-CF SERIES
The DS series pulse servo tensioner features pulse motor as the source of torque control torque, its sensitive and quick response feedback control system, providing precise, stable and consistent tension for high speed quality winding. Selected models of this series come with real-time tension measurement and display, provides A clear and convenient way to observe the winding tension, aiding in better control of product quality.
Built-in tension feedback and stabilizing control system, providing precise and consistent tension; pulse motor driver is integrated into internal controller. Two stage tension setting and wire breakage detection
Advantages :
High speed operation under high torque conditions, stable tension
- Wide selection of wire travel speed, maximum 12 M/S
- Clear LED status indicators
- Dual scale display, easy adjustment of main tension and second tension
- Dual spring tension control, wide tension range
- Built-in adaptive speed control
- Built-in wire break detection and alarm output
REQUIERMENTS :
Power Supply : DC 24V /48V
BASIC SPECIFICATIONS OF DSX-TT SERIES
| Model No. | Tension Range (G) | Max Wire Travel Speed (M/S) | Power Supply | Rated Current (A) | Suitable Wire Size (Mm) | |
| DS-CF-C07-45]200 | 1-200 | 7 | DC24V | 1.2 | 0.01-0.18 | |
| DS-CF-C07-45]1200 | 100-1200 | 7 | DC48V | 7.5 | 0.10-0.50 |
